Easy90 || Pass Through Hood Type Dishwasher
Pass Through Hood Type Dishwasher
Basket 50X50 - 3X400V/50 Hz. - Three Phase
Moulded wash tank with rounded corners and double wall (insulated hood upon request).
Full-width wash tank filters (on request).
Fully automatic operation with electromechanical controls.
Magnetic microswitch to cut out operation of the appliance when door is opened.
Useful washing height 40 cm, dish Ø44 cm.
Square basket 50x50 cm (supplied with 1 plate basket, 1 flat basket, 1 cutlery holders).
Independent lower/upper washing and rinsing arms.
Washing cycle time 75-180 seconds (capacity 960-400 pz/h).
Standard built-in rinse-aid pump.
Self-draining wash pump.
Built-in insulated boiler made in AISI 304L stainless steel.
Boiler and tank heating through thermostatically protected armoured heating elements (in exchange).
Tank capacity lt. 18 and boiler capacity lt. 8.
Water consumption per cycle lt. 3,5 - Water pressure input ATE 2,0-3,0 - Max temperature of inlet water 50°C.
Tank heating element kW 2,5 - Boiler heating element kW 6,0 (Cold water input kW 9,0).
Washing pump power Hp 1.
Noise level at 1 mt. < 70 dbA.
Dim: 697 X 725 X 1460 / 1940 mm
Total power kW 6,74.
Made in Mach, Italy
