RY10000B || ECOLOGY UNIT
RYDAIR ELECTROSTATIC AIR CLEANER (WITHOUT BLOWER)Industrial grade Electrostatic Air Cleaners for collection of dry and wet particulates like dust, oil mist, cooking fumes and various pollutants. Typical application include commercial kitchen exhausts, Air Handling Units (AHUs), factories, workshops, CNC machine shops and many other premisesDimensions/Weight H: 540 x W: 2338 x L: 620mm / 154KgCabinet Galvanized Steel, 1.4mm / 16 GaugeFinishing Powder Coated, Dark BlueAir Volume (Rated-Max)# CFM: 6000-8200; CMH: 10000-14000 L/s: 2800-3800Static Pressure 50 pa / 0.2”Voltage & Power 230 VAC +/-10%, 50/60Hz, 125WattsIonising Voltages High Voltage: 12KVdc, Low Voltage: 6KVdcPower Supply High Frequency solid state and self regulating designAir Flow Direction Default : Right to Left; Reversible : Left to Right
Pre-Filter Stainless Steel Wire Mesh, Washable x 4Electrostatic Cell H: 472mm, W: 550mm, L: 340mmNo of Cells / Weight 4/16.5KgNo Of Plates per Cell 59Total Collecting Area 24.28 Sq metersPost Filter (Optional) Stainless Steel Wire Mesh, Washable x 4Installation Ceiling Suspended; Wall or Frame Mounted, Multiple Units Stack
